Brands |
N/A NewAge Newloc® |
Material |
N/A Brass |
Tubing Outer Diameter (OD) |
N/A 3/8 x 1/4 in |
Union Type |
N/A Reducing |
Construction Body Materials |
N/A Brass |
Construction Collet Materials |
N/A Brass |
| Construction O-Ring Materials1 | N/A Buna-N |
| Working Pressure2 | N/A Up to 250 psi |
Full Vacuum Rating |
N/A 29.9 inHg |
| Working Temperature3 | N/A -10 to 200 ºF |
Note for Working Pressure, Full Vacuum Rating, and Temperatures |
N/A Values listed are typical for the material used in manufacture, except where noted, and are meant only as a guide to aid in design. Field testing should be performed to find the actual values for your application. |
Notice |
N/A NewAge Industries, Inc. has been a privately owned corporation since 1954. Neither the corporation nor its principals are affiliated, in any way, with any other group or entity either representing themselves as or being referred to by the term New-Age. |
Warranty |
N/A NewAge Industries' products are warranted to be free from defects in material and workmanship. Any product found to carry such defects will be replaced without charge. This warranty is limited only to the replacement of NewAge Industries' products, item for item, which after examination by NewAge Industries are deemed defective. NewAge Industries specifically disclaims any other liability. The data supplied is provided as a helpful guideline and is believed to be reliable; however, nothing stated shall constitute a guarantee, recommendation, or warranty for any application. |
Note |
N/A
Made in U.S.A. Use Newloc® Brass fittings with all types of semi-rigid to rigid plastic tubing including nylon and polyethylene. They may also be used with limited soft tubing sizes using tube supports (available). Pulling on the inserted tubing or increasing the pressure actually tightens the seal. Typical applications include systems for pneumatic control, robotics, instrumentation, and chemicals. Manifolds pre-mounted with Newloc® Brass fittings or nickel-plated Newloc® Brass (for improved aesthetics) are available - call for details. All male pipe threads come with a pre-applied sealant of fluoropolymer, however for subsequent use it is recommended that sealant, such as PTFE Thread Sealant be used. The push-to-connect fitting ends are self-sealing - do not use sealants at this connection. If tube disconnection is performed, it may be necessary to re-cut the end of the tubing to a 90º angle to ensure perfect sealing when reattached. All items sold in increments of 5 pieces. Specifications are subject to change without notice. |
